Product Description
Housing
-
Premium powder-coat, aluminum, dark bronze or black housing.
- 42.25" Tall x 6.3" Diamiter x Top is 9.76" Diamiter
-
Mounting
-
Anchor Bolt mount kit (Order separately).
Electrical
-
Operating temperature (ambient): -40°C to 60°C (-40°F to 140°F).
-
Universal 120-277V AC voltage (50-60Hz) is standard.
-
0-10VDC dimming drivers are standard.
-
Input transient surge protection = 4kV.
-
Power factor > 0.90.
-
Total Harmonic distortion < 20%.
Optical System
-
High-impact, Polycarbonate Lens.
-
Field selectable 3000k(warm white), 4000k (neutral white), and 5000k (cool white) color temperatures*.
-
Tri-lumen selectable delivers 1,700 to 3,000 nominal lumens*.
-
Long-life LEDs provide 192,000 hours of operation with at least 70% the initial lumen output (L70, and 58,000 hours with at least 90% the initial lumen output (L90*.
-
LED color maintenance < 0.00313 chromaticity shift (Δu’v’) over the initial 6,000
hours of operation.
-
Color rendering index > 70.
Code Compliance
-
cULus listed for wet locations.
-
Complies with FCC part 15, class A.
-
IP65 rated for ingress protection.
-
IK10 rated for impact protection.
Warranty
-
5-year warranty on all electronics and housing.
