Product Description
Housing
-
Premium powder-coat, die-cast aluminum, Bronze or White housing.
Mounting
-
Surface mounting.
Electrical
-
Operating temperature (ambient): -40°C to 45°C (-40°F to 113°F) .
-
Universal 120-277 AC voltage (50-60Hz) is standard.
-
0-10V DC dimming drivers are standard.
-
Integrated photocell is standard. Photocell can be enabled or disabled by a switch.
-
Input transient surge protection = 6kV.
-
PF > 0.9; THD < 20%.
Optical System
-
Polycarbonate lens.
-
Field selectable 3000K (warm white), 4000K (neutral white), and 5000K (cool white) color temperatures.*
-
Provides a range of 3,000 to 12,000 nominal lumens.*
-
Long-life LEDs provide 167,000 hours of operation with at least 70% of initial lumen output (L70), and 51,000 hours with at least 90% of initial lumen output (L90).**
-
Beam angle 135°.
-
Screw in sensor ready. Sensor and remote control sold separately. Remote control required to change factory sensor settings.
-
LED chromaticity based on < 6-step ANSI quadrangles.
-
LED color maintenance <- 0.0024 chromaticity shift (Δu’v’) over the initial 6,000
hours of operation.
-
Color Rendering Index > 80.
Code Compliance
-
cULus listed for wet locations.
-
Complies with FCC Part 15, class A.
-
IP65 rated for ingress protection.
-
IK10 rated for impact protection.
Warranty
-
5-year warranty on all electronics and housing.
Other Details
