Product Description
Housing
-
Die-cast aluminum housing with dark bronze powder coat finish.
-
Polycarbonate lens.
-
Optional NEMA photocell receptacle & photocell.
Electrical
-
Universal 120-277V (50/60Hz) or 277-480V (50/60Hz) AC voltage with 6-foot
incoming power cords.
-
0-10VDC dimming drivers are standard.
-
Watertight, compression-type electrical connectors.
-
Power factor > 0.90.
-
Total harmonic distortion < 20%.
Code Compliance
-
cULus listed for wet locations in ambient temperatures from -40°C to 50°C
(-40°F to 122°F).
-
Rated for 3G vibration.
-
Lenses are rated IK08.
-
Input transient surge protection (6kV).
-
Complies with FCC Part 15, class A.
-
IP65 rated for ingress protection.
*NEMA photocell sold separately
**Pole tenons and tenon adapters available
***L70 hours are IES TM 21 11 calculated hours.
Optical System
-
Field selectable 3000k (warm white), 4000k (neutral white), and 5000k (cool
white) color temperatures.
-
Long-life LEDs provide 162,000 hours of operation with at least 70% of initial lumen output (L70), and 49,000 hours with at least 90% of initial lumen output (L90).***
-
LED chromaticity based on < 6-step ANSI quadrangles.
-
LED color maintenance < 0.002 chromaticity shift (Δu’v’) over the initial 6,000 hours of operation.
-
Provides a range of 14,000 to 40,000 nominal lumens.
-
Color rendering index (Ra) > 80.
-
IES roadway distributions include types III & V.
Warranty
-
5-year warranty on all electronics and housing.
Mounting
-
Wall mount brackets and tenon adapters are available.
-
Easy installation in new construction or retrofit.
